Go-Karts
SPECIFICATIONS:
Engine ...................................................... 9 HP Honda GX-240 with silent muffler
Drive ........................................................ 38mm wide, 8mm pitch, Gates Polychain GT2 Belt
Size .......................................................... 48"W x 80 3/4"L X 37"H
Weight ...................................................... 470 Ibs.
Wheels ..................................................... Heavy-duty 9 ga. steel, 5" 3-hole
Tires ......................................................... 12 x 4.00-5 (extra-thick tread) slick
Brakes ...................................................... Twin 6" shoe-and-drum type
Seat ........................................................... Padded Naugahyde upholstered seat
Steering Wheel ........................................ Heavy-duty cast aluminum
Frame ....................................................... Steel tubing (.120" wall) MIG welded in jigs
Finish on Frame ....................................... Special powder coating is baked at 425° F-
SAFETY FEATURES:
Bumper ................................................................. 2-piece .360" x 3" spring steel, perimeter design
Padding ................................................................ Crotch pad on steering column support and steering pad on butterfly steering wheel
Shoulder Harness ............................................... 4-point padded harness, aircraft quality
Low Center of Gravity ..............................…....... The bottom of the chassis is well below the center of the wheels to prevent tipping
Roll Bar .................................................…….......... Combination headrest/roll bar integral with seatback, which is integral with the frame
Fenders ................................................................ Provides additional protection from wheel
Fuel System.......................................................... 3 gal. gravity feed tank
Floor Plate ....................................................….... Aluminum tread plate
Remote Engine Control....................................... R/C Systems
If you fail to follow the rules or instructions issued by the staff, or if you are removed from the track for the day, there will be No Refunds in this case.
